The sky’s the limit! If you can dream it, we can build it!

Call US:0122 375 0227

Fixed Lantern Rooflight

RLS SK02

Low Maintenance
Solar Control
Laminated Inner
Upstand
Do you require fitting?

Add to Enquiry Basket

Description of Fixed Lantern Rooflight

Product Details

The Lantern Rooflights have a contemporary design providing a more architectural feel. Giving added height and volume to your room, providing maximum light transmission and that all important WOW factor. The RLS lantern is a real showpiece and takes rooflight design one step further compared to the flat glass range. Designed to sit straight onto a flat roof (5 to 15 degree pitch).

Available in 3 different options;

  • Fixed Lantern Rooflights
  • Manual Opening Lantern Rooflights; or
  • Electric Opening Lantern Rooflights

As with all our products, the skylight, roof window or rooflight of your choice can be made to match your exact requirements.

The Fixed Lantern rooflights are ideal for those looking to increase the natural light into a room without the need for ventilation

The Manual Opening Lantern rooflights are best suited for those wanting contemporary design with the added functionality of allowing both natural light and ventilation. These are fitted with a telescopic screw-jack opener and supplied with a telescopic operating pole. The screw-jack has an opening stroke at 250mm.

The Electric Opening Lantern rooflights are ideal for those wanting all of the above, conveniently operated by the click of a switch. These come with a quality concealed opening mechanism, and is easy to operate. It’s factory-fitted with 24v chain-driven actuators which are completely concealed within the frame.

NOTES: Dimensions are external measurements & all prices are plus VAT.
Also, a fixing kit is supplied with this item, which will include all fixings needed for installation but the Opening (Electric) must be wired in and signed off by a qualified electrician (wiring diagrams will be sent with the rooflight).

Standard Size Rooflights
Delivery within 10-15 working days. We have a large selection of standard sizes available but if you require different sizes please create a Tailor Made option – entering your dimensions and add any available Optional Extras for an instant quotation.

Tailor Made Rooflights
Delivery within 2-3 weeks – view full Delivery information.
(*depending on what optional extras you select lead times may vary)

If your requirements are outside of these sizes please see call 0122 375 0227 or email sales@rooflightsolutions.co.uk to discuss your specific needs in more detail.

If you require fitting we will only take your order as an enquiry and will be in touch in one working day with a quote for installation.

Fixed Lantern Rooflight Specs

Technical Specifications

The Lantern Rooflights come with a 32mm DGU toughened safety glass with low-e coating and warm edge spacer. The low-e coating allows the suns natural heat (solar gain) to pass through the panes then the low-e coating reflects the heat gain back into the room, which is more energy efficient.

The warm edge spacer is made of an insulating plastic composite material that becomes a barrier to heat loss, keeping the edge of the unit warm, resulting in less heat loss.

Manufactured from 6063-T6 aluminium profile, thermally broken with 32mm polyamide insulation sections to prevent cold bridging and stop condensation. The frames are dual colour, coated with marine grade polyester powder coating; supplied in dark grey (RAL 7015) externally and white (RAL 9010) internally, as standard.

They come factory glazed, as one unit for ease of installation, for the best easy to fit solution include our Upstand which will give you the correct fall angle required.

Available in 3 different options;

  • Fixed
  • Opening (Manual); or
  • Opening (Electric)

NOTE: Dimensions are external measurements & all prices are pluc VAT.
A fixing kit is supplied with this item, which will include all fixings needed for installation but the Opening (Electric) must be wired in and signed off by a qualified electrician (wiring diagrams will be sent with the rooflight).

If your requirements are outside of these sizes please see call 0122 375 0227 or email sales@rooflightsolutions.co.uk to discuss your specific needs in more detail.

Warranty

Warranty
All of our products come with a 10 year warranty as standard with an independent 3rd party insurance company covering this. The length of the warranty can be extended at additional cost upon request.

Extended Warranty Periods - Upon Request Only

Painted Surfaces – 10 years

Glass – 10 years

Silicone Sealants – 10 years

Operating Gear – 12 months from date of purchase

Installation – 12 months from date of install

NOTE: Nickle Sulphide or any other inclusions in the glass that may cause a spontaneous breakage are not covered by the 10 year glass warranty.
They are an extremely rare occurrence and not covered by any of the glass manufacturers, whether the glass is Heat Soak Tested following Thermal Toughening or not.

To maintain these warranties you will need to follow the instructions detailed in our Operation & Maintenance (O&M) Guide.

If your require any assistance please call 0122 375 0227 or email sales@rooflightsolutions.co.uk to discuss your specific needs in more detail.

Delivery Details

Delivery
If in stock our rooflight(s) will be delivered to your chosen site within 10 working days. If your rooflight is manufactured to order depending on the sepcification we offer lead times of  3-4 weeks from the date of order (depending on service selected)

Deliveries will be made to kerbside or nearest accessible point, we cannot move the product to point of installation or inside your building so please ensure you take note of the product weight and ensure enough people are on site or have adequate equipment to move the product from the delivery point to your intended installation point. Due to our vehicle sizes used we may not be able to deliver to locations with restricted or narrow access, please contact our sales team who will be happy to advise.

Rooflight Solutions will advise an approximate delivery date within one week of the order being placed.

On the day of delivery, we will contact you 1hr prior to drop off so that you can ensure your arrangemnets to unload are in place and that a contact available to sign for the delivery, unfortunately for insurance reasons we cannot allow delivery of your rooflight unless somebody is there to sign for it. If no one is available to sign for delivery, the consignment will be returned and you will be charged the cost of the delivery.

Charges may be applicable if the courier is unable to complete the delivery due to site conditions.

Deliveries are made Monday – Friday only. We can deliver weekends upon request however additional charges may apply.

If your require any assistance please call 0122 375 0227 or email sales@rooflightsolutions.co.uk to discuss your specific needs in more detail.
